Horizontal clamp with a horizontal flange 800N
Horizontal clamp with a horizontal flange 800N
Horizontal clamp with a horizontal flange 800N
Horizontal clamp with a horizontal flange 800N

Horizontal clamp with a horizontal flange 800N

+ Add to compare
  • Kliknij i zobacz ten produkt oraz inne rozmiary
Size
uniwersalny
18,76 €
incl. VAT / pc
/ pc
Najniższa cena w ciągu ostatnich 30 dni przed wprowadzeniem obniżki: / pc
You can also buy using:
14 days for easy returns
Find out in which store you can check the product and buy it right away
Horizontal clamp with a horizontal flange 800N
Horizontal clamp with a horizontal flange 800N
uniwersalny
Safe shopping
Download technical information Print this page
Brand
PlacoGrip
Product code
70.1102.00800.0
Producer code
5905249601092
Product code
70.1102.00800.0
F max N
800
L
132
L1
51
L2
6
L3
5
H
34
h1
22
h2
9
m
2
d1
M5
d2
5,5
a
14
B
36
b
26
Jaw height
22
Jaw spacing
51
Kind
szybkozaciskowy
α
95

Quick-release clamp with adjustable working range. Option to choose the clamping screw from 2 models (ordered separately).

Material:

  • Knee lever mechanism: galvanized steel
  • Handle: soft PVC
  • Clamping screw: galvanized steel or oxidized steel
Horizontal clamp with horizontal flange - Technical drawing
